Cantilever Beam System

When overhead crane access is obstructed or limited, a cantilever beam system can provide access to remove or replace components in refineries, nuclear power plants, and other areas. Cantilever beams can be used with most hydraulic or conventional cranes and provide a safe and cost effective solution.

Features

  • Capacities up to 80T
  • Compact counterweight design allowing for a decrease in required headroom
  • Customizable rigging attachment points for a multitude of applications
  • Beam extensions available for increased reach
  • Wireless operation, allowing the operator mobility during lifting operations
  • Dual configurations are available for increased capacities

In our industry, cantilever beams are also commonly referred to as cantilever bars.

Request Information

Cantilever Beam Process

Cantilever Beam Process

Related Projects

Cantilever Bar Approach Helps Ease Exchangers Into Place

View Project
Cantilever Bar Approach Helps Ease Exchangers Into Place

Deep South used a cantilever beam (also commonly referred to as a cantilever bar), which incorporates a compact counterweight design with customizable rigging attachment points, to move eight 118,000-pound exchangers into position under an existing steel structure at a refinery optimization project in the Southwest.

Heavy lift tail crane

Tailing Over a Live Pipe Rack Emphasizes Complex Project copy

View Project
Tailing Over a Live Pipe Rack Emphasizes Complex Project copy

From a tricky bridge crossing to a complex coordinated lift, Deep South facilitated the delivery and setting of components for a petrochemical facility acid modification and upgrade project in Louisiana. The key components included a 627,000-pound acid settler, 689,000-pound first stage reactor, acid storage drums and associated parts.

tower take down

A One Lift Truss and Tower Take-Down

View Project
A One Lift Truss and Tower Take-Down

In the Southwest, a 100' diameter wood pellet bin caught fire and collapsed, compromising the 117,000-pound, 215’ long truss and tower conveyor system.
